1. Advantages:
92% AL2O3 alumina ceramic tiles and natural rubber plate for wear resistance liner combined with advantages of alumina ceramics and rubber, are beneficial to decrease downtime, maintenance cost and extend the service life of the equipment.
2. Brief Introduction:
92% AL2O3 alumina ceramic tiles and natural rubber plate for wear resistance liner are compounded by high alumina ceramics and excellent natural rubber through special process.The excellent damping performance of natural rubber can help to achieve some impact resistance which will prevent the tiles from cracking in areas of high impact, which achieves a vastly superior result to ceramic lining tiles which are bonded directly to the steelworks.
3. Main Technical Data of 92% AL2O3 alumina ceramic tiles and natural rubber plate for wear resistance liner
|
Items |
Index |
|
Alumina content |
≥92% |
|
Bulk Density |
≥3.63g/cm³ |
|
Rockwell Hardness (HRA) |
≥90 |
|
Compressive Strength |
≥850MPa |
|
Fracture Toughness |
≥4.8MPa.M1/2 |
|
Bending Strengt |
≥290MPa |
|
Thermal Conductivity 20℃ |
20W/m.k |
|
Coefficient of Thermal Expansion |
7.2×10-6m/×m.k |
| Young's Modulus 20℃ | 277GPa |
|
Shear Modulus 20℃ |
113GPa |
|
Surface Finish: As Fired |
1.27mm |
|
Color |
White |
